InFill Graft Delivery System

InFill Interbody Fusion SystemUp to 94% more bone graft volume to promote greater endplate contactMaximized Graft Volume

A controlled and complete fill that delivers maximum endplate contact was Pinnacle Spine’s goal in developing the InFill Graft Delivery System. Pinnacle Spine’s innovation offers physicians a simple and efficient solution when it comes to graft delivery – in situ:

  • Delivering a complete fill
  • Supplementing pre-packed graft material
  • Optimized contact with vertebral endplates

Download our InFill® Graft Delivery System Brochure

Coupled with the larger, single graft chamber of our implants, our system may help optimize fill, endplate contact and the formation of a robust fusion column.

delivery-plungers

  • Insertion tool or impactor guides cannula to the implant graft chamber.
  • Metal stylet allows for complete graft material delivery.
  • Locked cannula and plunger system, using the syringe or spindle drive, aids in tube fill.

1 Prep, 2 Fill, 3 InFill. Fill syringe, Transfer bone graft material into cannula, Deliver optimal graft volume for filling the biologic void.

InFill Cannula Volume

 OD (mm)ID (mm)GRAFT CHAMBER VOLUME (cc)
DISC FILL TUBE864.25

LATERAL FILL TUBE4.844.0

TLIF FILL TUBE3.52.51.0
